C3-200B Plus Controller with metal box

Model:

C3-200 Plus

Operation System

Linux OS

Hardware

CPU: Single Core @ 1.0GHz
RAM: 128MB; ROM: 256MB

Authentication Method

Card / Password / QR Code

Access Point Capacity:  C3-200 Plus: 2 Access Points

Reader Capacity:
C3-200 Plus: 4 * RS-485 Readers (ZKTeco RS-485 / OSDP), 4*26 / 34 / 66-bit Wiegand Readers

IO Expansion Board Capacity

8pcs EX0808 (RS-485 connection)

User Capacity

100,000

Card Capacity

100,000 (1:N) (Standard)

QR Code Capacity

100,000 (Static QR Code / Dynamic QR Code)

Transaction Capacity

500,000 (Standard)

Number of Inputs:
C3-200 Plus: 2 * Exit Button, 2 * DoorStatus, 2 * AUX Inputs or 64 (with 8pcs of EX0808 IO expansion board)

Number of Outputs:
  C3-200 Plus: 2 * Form C Relay forLock, 2 * Form C Relay forAux Output or 64 (with 8pcs of EX0808 IO expansion board)

Max. Card Length

Supports up to 66 bits Card Length

QR Code

QR code, PDF417, Data Matrix, MicroPDF417, Aztec scanning in third-party development projects.Dynamic QR codes on the ZKBio CVAccess mobile application.

Communication:
C3-200 Plus: TCP / IP * 1; RS-485: ZKTeco RS-485 / OSDP * 1; Wiegand (Input) * 4; USB: Type A (USB Drive Only) * 1; Aux Inputs * 2; Aux Outputs * 2; Electric Lock * 2; Door Sensor * 2; Exit Button * 2; Alarm * 2

Standard Functions

Webserver, Upto 14-digit User ID, Access Levels, Access Groups, Holidays, Anti-passback, Anti-tailgating, Linkage, Global Linkage, Multiple Verification Methods

Access Control Interface

Wiegand (Card Reader)
RS-485 ( RS-485 Card Reader / QR Code Reader)

Power Supply

9.6V - 14.4V DC

Operating Temperature

0℃ to 45℃

Operating Humidity

20% to 80% RH (Non-condensing)

Dimensions (mm)C3-200 Plus: 175 mm*99 mm*19.3 mm (L*W*H)

Gross Weight

C3-200 Plus: 0.296 Kg

Net Weight

C3-200 Plus: 0.190 Kg

Supported Software

ZKBio CVAccess

Installation

Supported Wall-mount with Metal Enclosure (Optional)

Enclosure (Optional)

 C3-200 Plus: Size: 350 mm*90 mm*300 mm (L*W*H); Material: SPCC steel; Power Supply Unit: input 110V~240V AC, output 12V 4A+1A DC; Backup Battery: Space reserved [Recommended Backup Battery size: 151 x 94 x 65 mm (L*W*H)] ; Gross Weight: 3.35Kg

Certifications

ISO14001, ISO9001, CE, FCC, RoHS

Factory ID

C3-200 Plus: AC02-C12H-U10
